Kioti
ID # 37659763

Kioti NX4510CH

Call for Price
Overview
 The KIOTI NX4510CH is a compact utility tractor with 45-horsepower, factory installed cab, and hydrostatic transmission It is ideal for small-scale ranchers needing a powerful machine for mowing, landscaping, and other chores.
Specifications
Model
NX Series
Category Name
Tractors
Year
2025
Sale Type
New
Manufacturer
Kioti
nx features

Eco-Friendly Diesel Engine

The whisper-quiet, eco-friendly KIOTI Tier 4 CRDI engine improves fuel efficiency while reducing noise levels. Silence and strength go hand-in-hand, letting you conquer every task with quiet confidence.

Projection and Working Lamp

 With the new projection head and working lamp, the operator will experience safer and easier operation after the sun goes down.

Hydrostatic Power Steering

 Hydrostatic power steering makes even the tightest, most repetitive turns a breeze. And for peak comfort, you can tilt the steering wheel to your perfect position with a simple push of a lever.

PTO Cruise

 Engage it with a tap, and your engine locks into a steady RPM, guaranteeing precise and efficient implement operation. Simply click the switch to adjust PTO speed on the fly—all without ever shifting gears or wrestling with the throttle.

Torque Compensation

 This feature acts like a master engineer, automatically adjusting the engine torque level to maintain a steady, unwavering flow of power.

Anti-Stall Function (HST Models Only)

 The Anti-Stall function seamlessly intervenes to safeguard against sudden stalls and keep your momentum going strong. For delicate tasks requiring extra control, set a maximum speed limit for safe and precise control.



engine
RPM
2,600 rpm
Model
3F183T
Power
45 hp (33.60 kW)
Fuel Type
Diesel
Aspiration
Turbo Charged?
Displacement
111.40 cu. in. (1,826 cc)
Fuel Capacity
14.80 gal (56 L)
Engine Manufacturer
KIOTI
transmission
Shuttle
Synchronized
Main Gear
None
Transmission
Hydrostatic
Travel Speeds Forward
16
Travel Speeds Reverse
16
Travel Speeds Maximum Speed
16.52 mph (26.59 km/h)
Travel Speeds Max Reverse Speed
16.52 mph (26.59 km/h)
hydraulics
Pump
Gear
Lift Capacity
3,177 lb (1,441 kg)
Pump Capacity
17.90 gpm (67.60 lpm)
pto 4
PTO Type
Independent
Mid Speed
2,000 (optional)
PTO Power
33.90 hp (25.30 kW)
Rear Speed
540 rpm
drive train3
Brakes
Wet Multi Disc
Clutch
None
Steering
Hydrostatic Power Steering
hitch 4
Type
Three Point
Category
Category 1
Control Type
Position with Draft Control
Lift Capacity
3,177 lb (1,441 kg)
dimensions 8
Width
65.60 in (1,665 mm)
Height
94.10 in (2,390 mm)
Weight
4,309 lb (1,954.50 kg)
Wheelbase
75.60 in (1,920 mm)
Rear Tread
52.10 in (1,324 mm)
Front Tread
55.20 in (1,352 mm)
Turning Radius
9.81 ft (2.99 m)
Ground Clearance
13.70 in (350 mm)
Length With Hitch
139.60 in (3,547 mm)
